Hydraulic Cone crusher is a kind of crushing equipment widely used in mining, building materials, chemicals, and other industries. HP100, HP200, HP300, and HP400 are different models of cone crushers, each with different characteristics and technical parameters.
HP100 cone crusher:
• Crushing capacity: 100 tons/hour, which can meet the production needs of different scales.
• Equipment size: length × width × height is 2600mm × 1500mm × 2000mm. It occupies a small area and is easy to install and transport.
• Motor power: 110kW, which can achieve energy saving and consumption reduction while ensuring the crushing effect.
The BAICHY cone crusher is the smallest model in the Baichy series of cone crushers. It is often used as a medium, fine, or ultra-fine crusher for aggregate production. It perfectly combines crushing speed, eccentricity, and crushing cavity type, with higher output, better product quality, and wider applicability.
HP200 cone crusher:
• Production capacity: 90-250t/h, divided into three crushing cavity types: ultra-fine, fine, and medium.
• Feed particle size: ≤185mm.
• Discharging range: ≥13mm.
• Motor power: 160kW.
• Features: Adopting laminated crushing cavity design, the product granularity is uniform, cube-shaped, and highly uniform. The equipment was optimized and switched to a fixed-shaft design, which has strong crushing power, low basic investment, and a large crushing ratio. The equipment components can be disassembled and assembled from the side or above, making daily maintenance convenient and fast. In addition, it is equipped with a PLC centralized control system and a touch-screen display to remotely monitor production conditions in real-time.
HP300 cone crusher:
• Moving cone diameter: 1120mm (44").
• Power: 220kW (300hp).
• Weight: 18100kg (39900lbs).
• Feeding port: 241mm (9 1/2").
• Maximum production capacity: 440Mtph (485Stph).
• Features: high degree of automation, uniform product particle size, good iron protection device, and can realize automatic cavity cleaning, increase the number of swings and rotations of the moving cone, thereby improving productivity. The sealing device adopts U-T type sealing, which has a better sealing effect.
HP400 cone crusher:
• Feed particle size: ≤299mm.
• Discharging particle size: <30mm.
• Production capacity: 140-630t/h.
• Features: Suitable for crushing harder rocks. The production capacity of the equipment is related to the discharging material. If the particle size of the discharging material is smaller, the production capacity will be relatively reduced.
In general, HP100, HP200, HP300, and HP400 cone crushers are different in terms of crushing capacity, equipment size, motor power, applicable materials, etc. Users can choose the appropriate model according to their own production needs.
