Mobile Quarry Machinery

Share
  • ≤480mm

    Feed Size

  • --

    Motor Power

  • 15-300t/h

    Capacity

Product Overview


Mobile quarrying machinery can quickly reach the designated location, provide the required sand and gravel aggregates, speed up the construction progress and improve the quality of the project. It can be used to crush rocks of various hardness, provide strong support for laying roadbeds and pavements, and ensure the stability and durability of roads; it can also handle various types of ore waste, realize resource recycling, save raw materials and reduce environmental pollution.

gravel-crushing-(Coarse-crushing,-Medium-crushing,-Fine-crus
Mobile Quarry Machinery
If you have any questions,you can ask customer service online !
leave message

Main types of mobile quarrying machinery


Mobile jaw crusher: commonly used for preliminary crushing operations in quarries.It has the characteristics of a simple structure, a large crushing ratio, and high output.The price varies depending on the model and configuration, generally ranging from tens of thousands to hundreds of thousands of yuan.

Mobile impact crusher: suitable for medium and fine crushing operations, capable of handling materials of various hardness.It has the advantages of high crushing efficiency, low energy consumption, and easy maintenance.

Mobile cone crusher: commonly used to handle high-hardness materials such as iron ore and granite.It has the characteristics ofa  large crushing force and uniform product particle size.

Mobile screening equipment: used to screen the crushed materials and separate products of different particle sizes. High screening efficiency and easy operation.

 Mobile Quarry Machinery  Mobile Crushers & Screens  MobiMobile Quarry Machinery  Mobile Crushers & Screens  MobiMobile Quarry Machinery  Mobile Crushers & Screens  Mobi

Working Principle
Mobile Quarry Machinery

 Mobile Quarry Machinery (5).jpg

Mobile quarrying machinery plays an important role in various occasions where on-site crushing, screening and processing of hard materials are required due to its high efficiency, flexibility and strong adaptability. They not only improve work efficiency and reduce costs, but also promote the rational use of resources and sustainable development of the environment.



Technical features of mobile quarrying machinery


1. Strong mobility: Mobile quarrying machinery usually adopts crawler or tire design, which is convenient for mobile operation in different sites.
2. High degree of automation: Modern mobile quarrying machinery is generally equipped with advanced control systems and sensors, which can realize automatic operation and intelligent monitoring.
3. High crushing efficiency: Advanced crushing technology and optimized crushing chamber design are adopted to improve crushing efficiency and product particle size uniformity.
4. Energy saving and environmental protection: Energy-saving motors and noise reduction technology are adopted to reduce energy consumption and noise pollution, which meets environmental protection requirements.

Specification

*The output will vary according to different materials, feed particle size and other factors
Model YDPZ46-1007 YDPZ46-900 YDPZ57-1210 YDPZ57-75 YDPZ96-1214 YDPZ96-160
Vibrating Feeder ZSW0625 ZSW0625 ZSW8530 ZSW8530 ZSW9638 ZSW9638
Primary Jaw Crusher PE400×600 PE400×600 PE500×750 PE500×750 CJ96 CJ96
Feeding Size (mm) ≤350 ≤350 ≤425 ≤425 ≤480 ≤480
Feeding Size (mm) 15-60 15-60 40-130 40-130 60-160 60-160
Secondary Crusher Impact crusher Cone crusher Impact crusher Cone crusher Impact crusher Cone crusher
Model PF1007 PYB900 PF1210 CS75 PFW1214 CS160
Feeding Size (mm) ≤250 ≤115 ≤400 ≤150 ≤430 ≤205
Capacity (t/h) 15-60 15-90 70-130 27-163 100-180 109-349
Vibrating Screen 2/3/4YK1237 2/3/4YK1237 2/3/4YK1848 2/3/4YK1848 2/3/4YK1860 2/3/4YK1860
Belt Conveyor B500x8m B650 B650 B650 B800 B800
 Capacity (t/h) 15-60 15-60 60-100 100-150 150-180 180-300
Overall Size(mm) 11500*2050*5400 11500*2050*5400 15800*2300*5850 15800*2300*5850 18000*2700*7650 18000*2700*7650
