A 350 t/h crushing production line configuration usually includes a variety of equipment to ensure efficient and continuous crushing operations. The following is a typical 350 t/h crushing production line configuration plan:
350 t/h crushing production line main equipment
1. Jaw crusher
Function: As a coarse crushing equipment, it is used to crush large pieces of material into smaller particles.
Recommended model: such as PE900×1200, etc. The specific model needs to be selected according to the material characteristics and output requirements.
2. Impact crusher/hammer crusher
Function: As medium and fine crushing equipment, the jaw crusher further crushes the material output.
Recommended models of impact crushers: such as PFW1315Ⅲ, PFW1318Ⅱ, etc. The specific model needs to be selected according to the material's hardness and output requirements.
Recommended models of hammer crushers: such as PCZ heavy hammer crushers DLPCZ1512, DLPCZ1612, etc., can be used directly as coarse crushing equipment, with the advantage of one-time crushing and molding.
3. Vibrating screen
Function: used to screen the crushed materials to obtain the finished product particle size that meets the requirements.
Recommended models: such as YKZ vibrating screen or TKQ medium vibrating screen. The specific model needs to be selected according to the screening efficiency and finished product particle size requirements, such as DL2YKZ2470, DL2YKZ2670, etc.
4. Conveying equipment
Function: used to connect various crushing equipment to achieve continuous conveying of materials.
Configuration: According to the process design and site conditions, different numbers and types of conveyors, such as belt conveyors, are configured.
350 tons/hour crushing production line auxiliary equipment
1. Feeding equipment
Function: such as vibrating feeder, used to feed materials into the jaw crusher evenly and continuously.
Recommended models: such as GZD1300×4900, etc.
2. Dust removal equipment
Function: used to collect and treat dust generated during the crushing process to ensure the cleanliness of the production environment and the health of workers.
Configuration: According to the dust generation and emission standards of the production line, select appropriate dust removal equipment, such as bag dust collector or wet dust collector.
3. Noise reduction equipment
Function: Used to reduce the noise generated by the crushing equipment and reduce the impact on the surrounding environment.
Configuration: According to the noise level and environmental protection requirements of the equipment, select appropriate noise reduction measures, such as installing a muffler or soundproof cover.
350 tons/hour crushing production line production line configuration example
1. Sandstone crushing production line
Equipment configuration: PE900×1200 jaw crusher, PFW1318 impact crusher, PFW1415 impact crusher, vibrating screen, etc.
Output: 350-400tph
Features: The entire production line is a three-stage crushing, which effectively utilizes the natural sand in the raw material, and then refines the aggregate in the raw material. The produced building materials have good particle shape and large output.
2. Limestone crushing production line
Equipment configuration: GZD1300×4900 vibrating feeder, PE900×1200 deep cavity jaw crusher, PFW1315 European impact crusher, 4YZS2460 vibrating screen, etc.
Output: 350tph.
Features: It occupies a large area, has a higher basic cost, but has strong production capacity. The crushed materials are screened to obtain finished materials of various specifications.
The configuration of the 350 tons/hour crushing production line needs to be comprehensively considered based on various factors such as material characteristics, production requirements, site conditions, and environmental protection requirements. When selecting equipment, attention should be paid to the comparison of equipment performance, quality, after-sales service, and price to ensure the stable operation and efficient output of the production line.
Price range of 350t/h crushing production line
The price of 350t/h crushing equipment ranges from tens of thousands to hundreds of thousands of yuan, and some high-end equipment may even cost more than one million yuan. The specific price depends on factors such as the type, configuration, and brand of the equipment.
Price differences between different types of equipment
1. Jaw crusher: Jaw crusher is a more common type of crushing equipment, and its price is relatively affordable. According to the market quotation, the price of a jaw crusher with a production capacity of 350t/h may be between tens of thousands and hundreds of thousands of yuan.
2. Impact crusher: Impact crusher has the advantages of high crushing efficiency and uniform particle size, and is suitable for crushing a variety of materials. Its price is usually slightly higher than that of a jaw crusher, but it is still within an acceptable range.
3. Cone crusher: Cone crusher is suitable for medium and fine crushing operations, and has the advantages of large crushing ratio, high efficiency, and convenient maintenance. Its price is usually higher, but the specific price needs to be determined according to factors such as the model, configuration, and brand of the equipment.
4. Double-roll crusher: A double-roll crusher is suitable for fine crushing operations, with the advantages of simple structure and convenient operation. Its price is relatively low, but the specific price needs to be determined according to the specific model and configuration of the equipment.
