4 1/4 Short Head Symons Cone Crusher with Hydraulic Adjustment
1. Overview
The 4 1/4 Short Head
Symons Cone Crusher is a high-performance crushing equipment suitable for many industries such as mining, smelting, construction, highway, railway, water conservancy and chemical industry, and is used for medium and fine crushing of various ores and rocks. This model adopts a hydraulic adjustment system, which can easily and quickly adjust the size of the discharge port to meet the crushing needs of different materials.
2. Main features of CS cone crusher
• Efficient crushing: Through the optimized cavity design and the combination of reasonable speed and stroke, this model can do more work under the same moving cone diameter, thereby improving the crushing efficiency.
• Uniform particle size: The laminated crushing principle is adopted to significantly increase the proportion of cubes in the product, reduce needle-like stones, and make the particle size more uniform.
• Good stability: When non-crushed objects such as iron blocks enter the machine, the iron protection device will automatically release them and then automatically reset. The iron overload protection has a fixed discharge port return point. After the iron passes through the crushing chamber, the original discharge port can be quickly restored.
• Easy to adjust: The hydraulic adjustment system can quickly and accurately adjust the size of the discharge port to meet the crushing needs of different materials.
3. Specifications of CS cone crusher 4 1/4 short head
• Model: 4 1/4 short head Symons cone crusher
• Crushing chamber type: short head type, divided into four types: fine, medium, coarse, and extra coarse
• Adjustment method: hydraulic adjustment
• Fine type: 109-181 t/h / Medium type: 132-309 t/h / Coarse type: 172-378 t/h / Extra coarse type: 236-455 t/h
4. Structural composition
Symons cone crusher is mainly composed of transmission part, support sleeve part, adjustment sleeve part, eccentric sleeve part, bowl-shaped bearing frame part, crushing cone part, feed support part, hydraulic and lubrication system, spring part (multi-cylinder is insurance cylinder part), etc. Compared with the standard type, the short head type has a longer parallel belt of the crushing chamber, which is suitable for places where the crushing feed particle size is small and finer product particle size is required.
5. Use and Maintenance
To ensure the normal operation of the equipment and extend its service life, regular maintenance should be carried out, including checking the oil level and oil quality of the hydraulic system, cleaning and replacing the filter, checking the wear of various components, etc. When adjusting the size of the discharge port, attention should be paid to the correct disassembly and assembly of the gravity adjustment device to avoid abnormal conditions caused by loss or improper disassembly.
